TTRPG Tools: Publish

TTRPG Tools: Publish is a helper plugin for people who publish their vault as a website (Obsidian Publish). It prepares content from:

• TTRPG Tools: Maps (Zoom Map) so your interactive maps can be displayed on your Publish site.
• TTRPG Tools: Timeline (Simple Timeline) so timeline code blocks can be rendered on your Publish site.

This plugin is intentionally separate from TTRPG Tools: Maps/Timeline:

• users who don’t use Publish don’t need the extra runtime and workflow,
• it keeps the Maps and Timeline plugins smaller,
• it creates room for Publish support for other tools without bloating the main plugins.

What it does

When you run one of the Prepare commands, the plugin:

1. Installs/updates Publish runtime

• Writes/updates a generated Publish runtime block into:
  • publish.js
  • publish.css
• It does not delete your existing content in those files; it only replaces the section between the markers:
  • BEGIN TTRPGTOOLS_ZOOMMAP_PUBLISH … END TTRPGTOOLS_ZOOMMAP_PUBLISH

2. Generates Publish data notes (maps / timeline)

• Converts internal data into publishable Markdown notes:
  • ZoomMap/publish/library.md (icons + collections + travel rules packs)
  • ZoomMap/publish/markers/m-<hash>.md (one per markers.json)
  • Timeline/publish/timelines/t-<hash>.md (one per timeline name; contains a JSON payload used by the Publish runtime)

3. Generates assets manifest notes

• Creates:
  • ZoomMap/publish/assets.md
  • Timeline/publish/assets.md

These notes link to:

• all data notes,
• all maps and asset files referenced by your published maps (bases, overlays, frames, stickers, baked SVGs, icon files, …).
• all notes and internal images referenced by published timeline entries.

Requirements

• Obsidian Publish
• Custom domain enabled (required by Obsidian Publish to use publish.js)
• TTRPG Tools: Maps (Zoom Map) installed and used in your vault (optional)
• TTRPG Tools: Timeline (Simple Timeline) installed and used in your vault (optional)

Storage requirement (important)

Publish support currently requires JSON marker storage (the default):

• marker data must be available as <image>.markers.json

If you use storage: note (inline marker storage), this plugin cannot export those maps yet.

Installation

Manual install (Obsidian community plugin):

• Copy the compiled plugin folder into:
  • <vault>/.obsidian/plugins/ttrpg-tools-publish/
• Reload Obsidian
• Enable the plugin in Settings → Community plugins

Setup (recommended)

1) Use the default Zoom Map library path

In TTRPG Tools: Maps settings, set Library file path to wherever you store your icon/collection library, e.g.:

• ZoomMap/library.json (recommended default)
• or a custom path (also supported)

Important: TTRPG Tools: Publish will read the library JSON from the TTRPG Tools: Maps setting (library file path). If the file is missing, it will try to call the plugin to export it automatically.

2) Mark notes as publishable (optional, recommended)

If you don’t want the plugin to scan your entire vault:

• add frontmatter to your published notes:

---
publish: true
---

Then keep Scan mode = Only publish: true notes in this plugin’s settings.

3) Timeline notes: required frontmatter

For timeline entries, the plugin scans notes that contain:

• a start date (default key: fc-date)
• a timeline list (default key: timelines)

Example:

---
publish: true
fc-date: 1165-03-01
fc-end: 1165-03-03
timelines: [Travelbook 1]
tl-title: Arrival in New York
tl-image: assets/my-image.png
tl-summary: |-
  Leave two empty spaces before you start the summary.
---

Notes:

• fc-end, tl-summary, tl-image are optional.
• tl-image can be an external URL or an internal vault file link/path.
• Month names on Publish can be taken from the TTRPG Tools: Timeline (optional setting) or overridden in this plugin’s settings.

Commands

Maps:

• “Maps: prepare publish (runtime + data notes + assets)”

Timeline:

• “Timeline: prepare publish (runtime + data notes + assets)”

Both:

• “Prepare publish (maps + timeline)”

Maps: one command (recommended)

Run:

• “Maps: prepare publish (runtime + data notes + assets)”

Then in Obsidian Publish:

1. Open Publish changes
2. Select:
   • publish.js
   • publish.css
   • ZoomMap/publish/assets.md
3. Click Add linked
4. Click Publish

assets.md is the “one-click selector” that pulls in all required files.

Timeline: one command (recommended)

Run:

• “Timeline: prepare publish (runtime + data notes + assets)”

Then in Obsidian Publish:

1. Open Publish changes
2. Select:
   • publish.js
   • publish.css
   • Timeline/publish/assets.md
3. Click Add linked
4. Click Publish

Individual commands

You can also run these separately:

• Maps: Install/Update publish.js + publish.css
• Maps: generate publish data notes (library + markers)
• Maps: generate publish assets manifest note +- Timeline
• Timeline: generate publish data notes
• Timeline: generate publish assets manifest note

What works on Publish

Maps

The Publish runtime renders maps as read-only interactive maps:

• pan / zoom
• marker rendering (including layers visibility)
• base images + overlays + viewport frame
• drawings and pattern overlays (baked SVGs)
• swap pins (right click cycles the frame)
• ruler / measurement (local, read-only)
• text layers

Editing markers on Publish is not supported.

Timeline

The Publish runtime renders timelines from pre-generated timeline data notes.

Supported code blocks on Publish:

Important:

• On Publish, timelines are not rendered by scanning your vault.

Files generated / modified

• Root of your vault (Publish runtime):

  • publish.js
  • publish.css

• Publish data folder (default):

  • ZoomMap/publish/library.md
  • ZoomMap/publish/markers/m-<hash>.md
  • ZoomMap/publish/assets.md
  • Timeline data folder (default):
  • Timeline/publish/timelines/t-<hash>.md
  • Timeline/publish/assets.md

Settings you might care about

Website

• Hover popover max width Controls the maximum width of Publish hover popovers (Page Preview) via generated CSS/runtime.
• Hide folders in publish navigation Lets you hide specific folders in the Publish navigation tree (purely visual; notes stay published and hover previews still work).

Notes

• The plugin avoids rewriting generated marker/library notes if the underlying JSON didn’t change, so Obsidian Publish won’t constantly recommend re-uploading unchanged files.
• The library JSON source path is taken from TTRPG Tools: Maps → Settings → Library file path (not hard-coded).

Roadmap

This plugin is intended as a shared “Publish bridge” for TTRPG Tools. Future versions may add more tools and more design options for Publish-rendered content.

License

MIT
