Media Gallery

Media Gallery is an Obsidian community plugin for rendering image, GIF, video, and audio galleries directly inside notes

It started as a fork and extensive rework of Luca Orio's Image Gallery plugin, which ATTRIBUTION.md credits, and keeps compatibility with the original img-gallery syntax while adding a broader mixed-media workflow

Flexible and convenient gallery for images, GIFs, videos, and music

Contents

• Highlights
• Supported Media
• Block Aliases
• Usage Modes
  • 1. Folder-Based Gallery
  • 2. Explicit Media List
  • 3. Combined Folder + Explicit Media
• Settings Inside the Block
• Layout Modes
  • vertical
  • horizontal
  • mosaic
  • collage
• Audio Features
  • Example: Audio-Heavy Block
• Plugin Settings
  • Performance
  • Paths
  • Audio
• Performance Notes
• Default Behavior
  • Folder galleries
  • Explicit media lists
• Examples
  • Mixed Media Dump
  • Search the Entire Vault
  • Path Patterns
  • Filters
  • Horizontal Strip
  • Gentle Mosaic
• Installing from Source
• Development Notes
  • Local validation

Highlights

• Renders galleries from a folder path or an explicit list of embedded files
• Supports images, GIFs, videos, and audio files in the same block
• Provides image lightbox with zoom, pan, double-click zoom toggle, and open-in-note action
• Opens videos and audio in focused modals with native playback controls
• Displays audio metadata, optional embedded cover art, waveform, and spectrogram previews
• Supports cache control from plugin settings for better memory/performance tradeoffs
• Keeps backward compatibility with img-gallery and img-gal

Supported Media

• Images: jpg, jpeg, png, gif, webp, tif, tiff, bmp, svg, avif
• Video: mp4, webm, mov, m4v, ogv
• Audio: mp3, m4a, wav, ogg, oga, flac, aac, opus

Block Aliases

The preferred code block name is:

```media-gallery
...
```

The following legacy aliases are also supported:

• img-gallery
• img-gal

Usage Modes

https://github.com/user-attachments/assets/b0a7af89-3c26-4a6e-97ea-a22f0b3843ed

1. Folder-Based Gallery

Use a vault-relative folder path to build a gallery dynamically

```media-gallery
path: media/Trip to Kazan
type: vertical
columns: 2
sortby: mtime
sort: desc
```

This mode scans the folder recursively. If path is omitted or set to *, **, ., or /, the plugin searches the whole vault

You can also use path patterns:

• path: media/** — recursive search under media/
• path: media/* — only direct children of media/
• By default, flexible wildcard patterns match file names, while the directory part only narrows the search scope
• Example: cats/cat? matches cats/cat1.png and cats/cat2.jpg
• This behavior can be disabled in plugin settings if you want wildcards to match the full path instead

2. Explicit Media List

Use embedded wiki-links, markdown image links, or direct paths/URLs

```media-gallery
columns: 2
type: vertical

![[photo.jpg]]
![[clip.mp4]]
![[track.mp3]]
```

This mode is ideal for Media Dump sections in daily, weekly, yearly, and hub notes

3. Combined Folder + Explicit Media

You can combine path with explicit embeds in the same block. The plugin loads media from the folder first, then appends explicitly listed items, while deduplicating identical entries by path

```media-gallery
path: media/Trip to Kazan
columns: 2
type: vertical

![[special-video-outside-folder.mp4]]
![[favorite-track.mp3]]
```

Settings Inside the Block

The plugin accepts YAML-like modifiers at the top of the block

Examples:

• extensions: jpg, png, mp4
• exclude: media/private/**, media/tmp/*, voice-note.mp3
• sortby: rand
• limit: 24
• seed: trip-2025

Layout Modes

https://github.com/user-attachments/assets/6f7ff6e7-17e1-46a0-bed1-d2fd9ad9118f

vertical

• Default mode
• Masonry-style multi-column layout
• Good for mixed Media Dump blocks

horizontal

• Row-based layout with fixed item height
• Better when order matters visually

mosaic

• Smart tiled collage layout
• Better for small curated image sets
• Defaults to fit: contain to reduce aggressive cropping

collage

• Alias for mosaic
• Preserved for convenience and compatibility

Audio Features

• Audio cards show track name, file type, and optional subtitle from metadata
• MP3 metadata parsing supports title, artist, album, and embedded cover art when available
• Audio modal can autoplay when opened
• Waveform is used by default
• Spectrogram can be enabled per block with spectrogram: true
• Audio visualizations can be disabled globally in plugin settings

Example: Audio-Heavy Block

```media-gallery
type: vertical
columns: 2
spectrogram: true

![[track-01.mp3]]
![[track-02.flac]]
![[track-03.m4a]]
```

Plugin Settings

Performance

• Enable cache — caches the vault media list and folder lookups in memory

Paths

• Enable flexible path patterns — enables advanced wildcard patterns such as media/**/concert* or media/2025-??
• Exact folder paths, folder/*, and folder/** stay on the fast path either way
• Match wildcards against file names — when enabled, wildcard parts match file names and the directory part only scopes the search; when disabled, flexible wildcards match against the full path

Audio

• Enable audio visualizations — toggles waveform and spectrogram rendering
• Autoplay audio on open — starts playback automatically when opening an audio card

Performance Notes

• Cache is invalidated when files are created, deleted, or renamed in the vault
• Turning cache off reduces memory usage but makes each gallery render rescan vault files
• Spectrograms are heavier than waveforms; use them selectively in large notes
• Audio spectrogram previews are rendered to canvas for better scroll performance than large DOM grids

Default Behavior

Folder galleries

• type: vertical
• fit: cover
• height: 260
• gutter: 8
• limit: 0

Explicit media lists

• type: vertical
• fit: cover
• height: 260
• gutter: 8
• radius: 10
• waveform: true
• spectrogram: false
• limit: 0

Examples

Mixed Media Dump

```media-gallery
columns: 2
type: vertical

![[photo-1.jpg]]
![[photo-2.jpg]]
![[clip.mp4]]
![[voice-note.mp3]]
```

Search the Entire Vault

```media-gallery
path: "*"
type: vertical
columns: 2
```

path: "**" works the same way as path: "*"

Path Patterns

```media-gallery
path: media/**
type: vertical
columns: 2
```

```media-gallery
path: media/*
type: vertical
columns: 2
```

Filters

```media-gallery
path: media/**
extensions: jpg, png, mp4
exclude: media/private/**, media/tmp/*
sortby: rand
limit: 24
seed: trip-2025
type: vertical
columns: 2
```

Horizontal Strip

```media-gallery
type: horizontal
height: 280
gutter: 12

![[photo-1.jpg]]
![[photo-2.jpg]]
![[photo-3.jpg]]
```

Gentle Mosaic

```media-gallery
type: mosaic
fit: contain
height: 280

![[photo-1.jpg]]
![[photo-2.jpg]]
![[photo-3.jpg]]
```

Installing from Source

1. Build or copy main.js, manifest.json, and styles.css
2. Place them in your vault under .obsidian/plugins/media-gallery/
3. Reload Obsidian
4. Enable Media Gallery in Community Plugins

Development Notes

Local validation

npm ci
npm run check:types
npm run lint
npm run build

npm run lint uses eslint-plugin-obsidianmd, which is the same family of checks recommended by the Obsidian submission bot for local preflight validation

Use npm run check:types, npm run lint, and npm run build before release changes. src/ is now the source of truth for the shipped main.js

Path errors can be disabled in plugin settings via Show path and empty-gallery errors if you prefer empty blocks over inline error messages
