Lean Terminal

An embedded terminal panel for Obsidian, powered by xterm.js and node-pty. Run shell commands directly inside your vault workspace - no external windows needed.

Desktop only. Requires Obsidian 1.5.0+.

Features

Terminal Core

• Full PTY terminal (not a simple command runner) with interactive shell support
• Auto-detects your shell: PowerShell 7 / Windows PowerShell / cmd.exe on Windows, $SHELL on macOS/Linux
• Startup command: configure a command that runs automatically in every new tab once the shell is ready (e.g. claude, npm run dev)
• Clipboard support: Ctrl+V / Cmd+V paste, Ctrl+C / Cmd+C copy (with selection)
• Clickable URLs in terminal output
• Auto-resize as the panel resizes
• Shift+Enter inserts a newline without submitting (muscle memory for Claude Code users)

Tab Management

• Multiple tabs with rename, color-coding, and pinning support
• Drag tabs to reorder them in the tab bar
• Keyboard shortcuts: Next/Previous (with wrap-around), Jump to Tab 1-8, Jump to last - bindable under Settings > Hotkeys
• Tab bar positioning: Top (default), Left, or Right side for wide-monitor layouts

Vault Integration

• Opens in vault root by default; command palette to open in the current file's folder; right-click any file or folder to open a terminal there
• Drag files from the Obsidian file explorer or Windows Explorer into the terminal to insert the absolute path (spaces auto-quoted)
• Wiki-link autocomplete: type [[ in the terminal to pick any vault note and insert as a wiki-link, vault-relative path, or absolute path

Search & Selection

• In-terminal search bar (Ctrl+Alt+F): match counter, case-sensitive toggle, and highlight decorations
• Copy on select: automatically copies selected text to the clipboard as you highlight

Appearance & Configuration

• 12 built-in color themes (Obsidian Dark, Obsidian Light, Monokai, Solarized Dark, and more); extend or override via themes.json
• Custom background color override with color picker (match your vault theme)
• Customizable ribbon and panel tab icon (any Lucide icon name)
• Configurable: shell path, font size, font family, cursor blink, scrollback, panel location

Sessions & Persistence

• Session persistence: tab names, colors, working directories, and scrollback are restored when Obsidian reopens
• Rescue recently closed tabs from the command palette (ring buffer of the last 10 sessions)
• Notification sounds when background tab commands finish (4 sound types, adjustable volume)
• Optional Claude Code integration: auto-maintained session registry with clickable Resume links and URI handler

Installation

Via BRAT (recommended)

1. Install the BRAT plugin if you don't have it
2. Open Settings > BRAT > Add Beta Plugin
3. Enter: sdkasper/lean-obsidian-terminal
4. Enable the plugin in Settings > Community Plugins
5. Go to Settings > Terminal > Download binaries and click Download - this fetches the native terminal binary for your platform (the platform-specific node-pty zip from the GitHub release; Obsidian itself only uses main.js, manifest.json, and styles.css)
6. Open the terminal via the ribbon icon or command palette

Manual Installation

1. Clone this repository
2. Run npm install && npm run build
3. Run node install.mjs "/path/to/your/vault"
4. Restart Obsidian and enable the plugin in Settings > Community Plugins

How It Works

The plugin uses xterm.js for terminal rendering and node-pty for native pseudo-terminal support. node-pty spawns a real shell process (PowerShell, bash, etc.) and connects its stdin/stdout to xterm.js via Obsidian's Electron runtime. This gives you a fully interactive terminal - not just command execution.

On Windows, the plugin uses the ConPTY backend (correct UTF-8 and emoji support). A patched windowsConoutConnection.js replaces node-pty's Worker thread with inline socket piping so ConPTY works inside Obsidian's Electron renderer, which does not support Worker thread construction.

Related documents

See Usage for the full command reference.

See Settings for all configuration options.

See Session Persistence for how tab state is saved and restored.

See Claude Code Integration for setup and usage.

See URI Handler for the obsidian://lean-terminal protocol reference.

See Security for the security review summary.

Changelog

See CHANGELOG.md for release history and feature documentation by version.

Feedback

Use this repo to report bugs, request features, or ask questions.

• Report a Bug
• Request a Feature
• Report a Performance Issue
• Ask a Question / Share Feedback

If you want to support my work, you can use this link to buy me a drink - thank you, I appreciate you.

Development

npm install
npm run dev          # Watch mode (auto-rebuild on save)
npm run build        # Production build
node install.mjs     # Install to default vault (D:\LOS Test)

Contributors

This plugin is built and maintained by a dedicated community. Special thanks to:

• @FarhadGSRX - Session persistence, session rescue buffer, Claude Code integration with registry generation and resume links, color scheme catalog with themes.json support
• @ckelsoe - Per-tab color tint customization with editable palette, wiki-link autocomplete with path-insertion modes
• @c00llin - Terminal location options (Tab Right, Split Tab Right)
• @kkugot - Emoji rendering fixes, system theme detection with terminal color reporting protocol
• @CHodder5 - Zsh startup file forwarding (.zshenv and .zprofile) via ZDOTDIR override

License

MIT
