Execute code inside your notes — a notebook that lives in plain Markdown. VS Code–quality syntax highlighting, live code execution with streaming output, shared variables across blocks, inline graphs, and styled HTML/PDF export — all in a plain-text .md file you can version, diff, and edit anywhere. No kernel, no .ipynb, no server.

CodeSuite in action

At a glance

	Feature	What it does
🎨	Syntax highlighting	Shiki (the VS Code engine) — 65+ themes, import any VS Code `.json` theme, in Reading view, Live Preview and Source mode
▶️	Live code execution	Run Python, JS/TS, Bash, Go, Ruby, PHP, and 8 more — output streams live, with interactive stdin and cancel
📈	Inline graphs	`plt.show()` / `fig.show()` render below the block — Matplotlib as images, Plotly as interactive widgets
🔗	Notebook variables	Shared state across blocks; declare note-wide `vars`; reference any value inline in prose with `$varname`
📎	Embedded files	`![[script.py]]` becomes a collapsible, highlighted, runnable block; open vault code files in a lightweight editor
🔁	Jupyter import/export	Convert `.ipynb` notebooks to/from notes — round-trips multi-language blocks correctly
📄	HTML / PDF export	Export a note with its code outputs (text, images, plots) to a self-contained, theme-matched file

🎨 Highlight

65+ built-in themes — Gruvbox, Catppuccin, Dracula, Nord, Tokyo Night, One Dark Pro, Rosé Pine, Kanagawa, Everforest, Solarized, Night Owl, Synthwave '84, and many more
Import any VS Code theme — load a .json file from vscodethemes.com or exported directly from VS Code
Auto light/dark switching — set a separate theme for each mode; CodeSuite switches when Obsidian's appearance changes
36+ languages with common aliases (py, js, ts, rb, …)
Editor highlighting — full token colors in Live Preview and Source mode via a CodeMirror 6 ViewPlugin, not just in Reading view
Full chrome in Live Preview — code blocks and ![[file.py]] embeds render with the same header, Run/Copy buttons, live output, line numbers, and collapse as Reading view. The block your cursor is in reveals its raw source for editing; every other block shows the rendered chrome, with running output preserved as you move around

▶️ Run

Run code directly from a code block — no terminal, no switching apps.

Language	Command	Notes
Python	`python3`	Matplotlib & Plotly graph capture, venv support
JavaScript	`node`
TypeScript	`npx tsx`
Bash	`bash`	Shared variable state across blocks
Zsh	`zsh`	Shared variable state across blocks
Shell	`sh` (POSIX)	`shell` and `sh` fences both run POSIX sh; source-file startup support
PowerShell	`pwsh`	macOS/Linux/Windows when PowerShell 7+ is installed
Go	`go run`
Ruby	`ruby`
Lua	`lua`
Perl	`perl`
R	`Rscript`
PHP	`php`	Automatically prepends `<?php` for snippets that omit the opening tag
Swift	`swift`

Live streaming — stdout and stderr appear as the process runs, not after it finishes
Interactive stdin — an input bar appears automatically when your code calls input() or reads from stdin
Password masking — sudo is detected automatically; the input bar masks characters for sensitive prompts
Inline graphs — plt.show() and fig.show() are intercepted without a display server. Matplotlib figures render as static images; Plotly figures render as interactive HTML widgets (zoom, pan, hover, legend toggles). Click a plot for full-screen view; hover an image for copy/download buttons. Toggle interactivity and offline Plotly.js embedding in settings. By default plots use Matplotlib's own look — to theme every plot (e.g. to match a dark vault), set Settings → Python → Matplotlib style to a built-in style name such as dark_background or seaborn-v0_8-darkgrid, or an absolute path to a .mplstyle file

More execution options — venv, PHP snippets, shells, interpreter paths

Virtual environment support — point the Python path to a venv binary; CodeSuite sets VIRTUAL_ENV and prepends bin/ to PATH so all venv packages are available across every language block
PHP snippet mode — PHP blocks can omit the opening <?php tag; CodeSuite adds it only to the temporary execution file
Shell startup support — Bash/Zsh can run as login shells, and Bash/Zsh/Shell blocks can source one or more startup files before your snippet runs
Explicit interpreter paths — pin exact binaries for bash, zsh, and sh/shell under Settings → Environment; useful if Obsidian's PATH differs from your terminal's, or to point shell blocks at a modern bash
Environment management — combine a shared .env file with per-vault overrides, source shell startup files, run Bash/Zsh as a login shell, or pin exact interpreter paths

🔗 Notebook mode: shared variables & Run All

Each note maintains an in-memory execution session — notebook-style shared state, scoped per note and held in memory.

Shared state across blocks — variables, imports, and function definitions carry over between runs (Python, Bash, and Zsh)
Live cross-language variables — a shared variable changed by one block is visible to later blocks in any language, in execution order. Set count = 42 in Python and a later Bash block sees 42; change it in Bash and the next Python block sees the new value. Scalars and JSON structures cross languages; rich objects (functions, DataFrames) stay within their language. See Variable typing & the execution model.
Inline $varname substitution — write `$result` anywhere in your note; it updates live in Reading view after each run
Run All — runs every executable block top-to-bottom, stopping on the first error; the view scrolls along and highlights the executing block. Skip a block with a skip fence tag or a codesuite:skip comment marker
Queued runs — with shared context on, clicking Run on several blocks queues them in click order; a queued block's button shows Queued (click again to cancel)
Clear Session / Copy output — reset accumulated state or copy any successful run's output from the note header

vars blocks & code_vars: frontmatter — typed, note-scoped variables

vars blocks declare note-scoped variables once; they are injected into every run as native, correctly-typed literals:

```vars
threshold = 0.85          # float
crawl_depth = 5           # int
download_assets = True    # bool
base_url = "https://x"    # string (one layer of quotes stripped)
dataset = sales_q4.csv    # bare text is a string too
```

Types are inferred from how each value is written, so in Python crawl_depth is an int, download_assets is a bool, and base_url is a clean string.

code_vars: frontmatter declares the same variables in YAML when you prefer note metadata over a fenced block:

---
code_vars:
  threshold: 0.85
  dataset: sales_q4.csv
---

A nested mapping like this shows an "unsupported property type" warning in Obsidian's Properties panel. CodeSuite hides that warning and, by default, renders the values as a read-only CodeSuite variables list just below the Properties widget. Turn the CodeSuite variables panel setting off to hide the list too, or write code_vars as a list of key = value strings (- threshold = 0.85), which Obsidian renders natively.

A vars block in the body wins if both define the same key.

State is per-note, lives only in memory, and resets when Obsidian is closed. For the full details on variable types, :type hints, multiline strings, cross-language propagation, and the execution model, see docs/variables-and-execution.md.

📎 Embed & render

Embedded code files — embed any code file from your vault with ![[file.py]] and get a full syntax-highlighted, interactive block instead of plain text:

Collapsible by default — header shows the filename and line count; click to expand
Supports Run, Copy, and all execution features just like inline blocks
Inline blocks can also be made collapsible from settings — useful for long preludes you only want to skim

Vault code files & external aliases — enable Settings → CodeSuite → Show code files in the file explorer (on by default) and Obsidian surfaces every supported code extension (.py, .js, .ts, .sh, .go, .rb, …) in the file explorer:

Syntax-highlighted preview mode (Shiki, same theme as your code blocks)
Switch to edit mode for a lightweight in-vault editor (2-space tab insertion, autosave)
A Run button for any executable language with live streaming output and Cancel support
Import code file as alias… (command palette) symlinks an external file into your vault under Imports folder (default CodeSuiteImports/) — edits write through to the real file on disk

HTML live preview — render html blocks as live HTML in a sandboxed iframe

Render an html code block as live HTML instead of showing its source.

```html preview
<div style="padding:8px;border-radius:6px;background:#83a598;color:#1d2021">
  Rendered inline ✨
</div>
```

Per-block flags on the fence info string: preview (or render) forces live preview; source (or raw / code) forces the source view
Global default — toggle Render HTML blocks in settings to preview every html block automatically
Preview/Code toggle — eligible blocks get a header pill to flip between rendered output and source
Embedded .html files — pass the flag in the embed alias: ![[page.html|preview]] or ![[page.html|source]]
Full documents — <head>, <style>, and <script> all work; a <!DOCTYPE html> page renders as-is, a bare fragment inherits your Obsidian theme

The HTML renders in a sandboxed iframe (sandbox="allow-scripts", no same-origin). Scripts run and styles apply, but only inside the frame — they cannot reach your vault, the rest of the app, or Obsidian's API.

Export a block to PDF (invoices, reports, certificates) — turn on PDF export for HTML blocks in settings and rendered html blocks get a PDF pill that opens a menu:

Save as PDF… — renders just that block on an A4 page and saves it next to the note (<note name>.pdf), ideal for archiving an invoice into its folder
Print… — opens the system print dialog for the block alone

Both honour the block's own CSS, including @media print rules, and lay it out on A4 with comfortable margins. Opt a single block in or out with a pdf (or nopdf) fence flag — pdf alone also renders the block — so you don't need the global setting on:

```html pdf
<div class="invoice">…</div>
```

Desktop only (both paths need Electron).

Data-driven documents (invoices, reports) with template — add a template flag and an html block becomes a template: it interpolates the note's frontmatter, includes a shared layout/CSS partial, and loops over a list. Keep one invoice.html partial and fill it per note — then the PDF pill exports it.

```html template pdf
{{> invoice }}
```

invoice_number: "2026-002"
client_name: "Muster GmbH"
items:
  - { description: "Wartung & Server", amount: 120 }
amount_net: 120
template_context:
  biz: "[[Business Config]]"

{{ field }} interpolates (HTML-escaped; {{{ }}} or | raw for trusted markup); {{ amount | eur }} and | date format while frontmatter stays raw and Dataview-queryable
{{> partial }} pulls in shared layout/CSS from your imports folder; {{#each items}}…{{/each}} loops; {{#if}} drops empty rows
template_context: exposes another note's frontmatter under a namespace ({{ biz.biz_iban }}) — change Business Config.md once, every invoice updates
Opt-in — the template flag, or the HTML block templating setting for any {{-containing block. Off by default so framework demos that use {{ }} render literally

…or template an embedded file — keep the layout in a standalone .html file and embed it; the file is templated against the embedding note. Cleanest for one-file documents like invoices — the note holds only data and one line, no fenced block needed:

![[invoice.html|template pdf]]

The same engine, flags (template / notemplate / pdf), and global settings apply.

Full syntax reference: HTML Templating. A copy-paste starter lives in examples/invoice/.

Move work between CodeSuite and the Jupyter ecosystem, or share a polished copy of a note. All four commands live in the command palette (desktop only).

Jupyter notebooks (.ipynb)

Import Jupyter notebook (.ipynb)… — code cells become fenced code blocks in the notebook's language; markdown cells become note prose. Notebooks import unrun so you re-run blocks in CodeSuite.
Export note to Jupyter notebook (.ipynb) — every executable block becomes a code cell; blocks in a non-dominant language carry a metadata.vscode.languageId tag so VS Code renders each cell in the right language and the notebook round-trips correctly on re-import. Cells export without outputs.

Styled HTML & PDF (with outputs)

Export note to HTML (with outputs)
Export note to PDF (with outputs) (rendered via Electron's print engine)

Both produce a self-contained file that matches what you see in Obsidian — same Shiki theme, CodeSuite styling, code outputs (text, images, plots), and native Obsidian features including callouts (theme colours, icons, and custom callout types) and LaTeX math (inline and block). Each export opens a small options dialog (last choices remembered):

Content width (HTML + PDF) — Obsidian default, Match current view, or Full width
Keep code blocks together (PDF) — avoid splitting a block across a page break
Single long page (PDF) — one continuous page with no page breaks

Outputs come from the live render. Open the note in reading view and run the blocks you want shown (individually or with Run All), then export. Whatever output is on screen is captured as-is; nothing is written back into your .md. If the note isn't in reading view, the command is unavailable.

Bake outputs into the note (for sharing) (advanced — off by default)

HTML/PDF export produces a separate file. Baking instead writes the output into the note's markdown, so it survives anywhere the raw .md is read — most importantly in shared notes (e.g. via NoteColab), where the recipient opens the note in a web viewer that has no CodeSuite to re-run your code. Without baking, a shared note shows your code but no output.

Enable it under Settings → CodeSuite → Sharing (baked outputs). Most users never need this; leaving it off changes nothing. Once on, two commands appear:

Bake code outputs into note (for sharing) — for every code block you've run, serializes its current output into a hidden ```codesuite-output block placed right after it. Run your blocks first, then bake.
Clear baked outputs from note — removes every baked block and its figure files. Fully reversible.

CodeSuite renders baked blocks as normal output panels (reading view and live preview); other markdown renderers fall back to a labelled code block. Two things are handled deliberately:

No note bloat — figures (e.g. matplotlib plots) are written as image files in a configurable folder (default CodeSuite/baked-outputs) and referenced by name, not inlined as base64. A Inline images instead of files toggle is available if you'd rather keep the note self-contained at the cost of size. (Interactive Plotly widgets have no static image form, so they're always inlined.)
No stale media — figure filenames embed a hash of their source code, so re-baking after an edit writes fresh files and the old ones are swept automatically. The baked panel also shows a stale badge when the code above it has changed since the output was baked — re-run and re-bake to refresh.

Installation

Community Plugins (recommended) — Settings → Community Plugins → Browse → search CodeSuite → Install → Enable.

Manual install

Download main.js, manifest.json, and styles.css from the latest release
Create <vault>/.obsidian/plugins/code-suite/
Place the three files inside it
Reload Obsidian and enable CodeSuite in Settings → Community Plugins

Configuration

Open Settings → CodeSuite — organized into Appearance, Execution, Languages, Files, and Advanced tabs — to configure themes, code execution, environment variables, and embedded file behaviour.


Variables & Execution	How to run code, declare variables, use `$varname`, cross-language propagation, practical patterns
HTML Templating	Data-driven `html` blocks — interpolation, filters, partials, loops; the invoice/report workflow
Configuration Reference	Every setting, option, and environment knob

Known limitations

Active-line highlight bleeds into code blocks (editor mode) — when the cursor is inside a code block in Live Preview or Source mode, Obsidian's active-line highlight shows through the block background. This is inherent to how Obsidian's active-line extension works.

Workaround: Enable Auto-switch theme and choose a theme whose background matches Obsidian's active-line color — the bleed becomes invisible.

Roadmap & changelog

Track progress or vote on the linked GitHub issues.

#	Feature	Issue
1	Per-block code formatting — line highlighting `{1,5-10}`, diff highlighting `ins`/`del`, per-block titles, `showLineNumbers` override, and inline code syntax highlighting	#13

Recent releases

1.16.3 — maintenance release: cleared the remaining @typescript-eslint/no-unnecessary-type-assertion warnings from the plugin review (#43) — removed redundant setTimeout/loadTheme casts, turned the file-picker cast into a type annotation, and routed frontmatter narrowing through a toRecord() helper that's valid in every type environment. No functional changes.
1.16.2 — maintenance release: cleared ~200 @typescript-eslint/no-unsafe-* warnings from the Obsidian plugin review (#43) by giving the Node built-ins (fs/path/os/child_process) self-contained type definitions instead of as typeof import(...) casts that collapsed to any without @types/node. No functional changes.
1.16.1 — bash/zsh/sh code blocks now run under WSL on Windows (#42). The temp script was passed to WSL as a Windows path (C:\…) it couldn't resolve; it's now translated to its /mnt/c/… form. A new WSL path translation setting (Auto-detect / On / Off) lets you override the detection for Git Bash, Cygwin, or MSYS.
1.16.0 — HTML and PDF exports now reproduce two more native Obsidian features: callouts (theme colours, icons, and custom callout types) and LaTeX math (inline and block), captured from the live note so they match your active theme in the standalone file. Fixes: embedded html-block previews no longer collapse to a 60px sliver in PDF export — the hidden print window keeps its layout timers running and waits for every preview iframe to report its true height before printing, and display equations render as a scaled, centred block instead of overflowing or being clipped.
1.15.0 — the settings tab is reorganized into five sections — Appearance, Execution, Languages, Files, and Advanced — navigated by a tab bar at the top instead of one long scroll (#31). Every existing setting is preserved; the tabs are keyboard-navigable (arrow keys, Home/End) and follow Obsidian's settings style guide.
1.14.2 — lint compliance: dropped the !important on the frontmatter-vars hide rule in favor of higher selector specificity, and removed leftover demo-GIF planning comments from the README. No functional changes.
1.14.1 — the code-block Copy button no longer appends a trailing newline, so pasting a single-line command into a terminal no longer auto-executes it (#37).
1.14.0 — the CodeSuite variables panel (the read-only rendering of code_vars: / template_context: below the Properties widget) is now reliable and on by default. It lives inside the note header next to Properties, so it stays put as you scroll instead of flickering, and it refreshes when the frontmatter changes. Turn it off in settings to just hide Obsidian's "unsupported property type" warning and render nothing (#34).
1.13.0 — reading-view and export polish: every code block is now collapsible from its header (#32); nested code_vars: / template_context: frontmatter renders in preview instead of Obsidian's "unsupported property type" warning, and code_vars accepts a key = value list form (#34); html-block previews now appear in HTML/PDF exports (#33). Fixes: re-running a block now sees upstream state instead of compounding its own output (#36), and dead output-toolbar buttons no longer show in exports (#35).
1.12.0 — HTML templating: an html template block — or an embedded .html file (![[invoice.html|template pdf]]) — becomes a data-driven document. {{ frontmatter }} interpolation with eur/date/number filters, {{> partials }} for shared layout/CSS, {{#each}} loops, {{#if}} conditionals, and template_context: notes for single-source shared data. Built for invoices/reports; pairs with the PDF pill. Opt in per block/embed with a template flag or globally with HTML block templating. See HTML Templating.
1.11.0 — PDF export for HTML blocks: rendered html blocks get a PDF pill to save or print just that block on an A4 page (great for invoices and reports). Opt in globally with PDF export for HTML blocks, or per block with a pdf / nopdf fence flag.
1.9.3 — execution and output-panel fixes: re-running a block after Run All no longer throws a NameError, the spurious trailing blank line in output is gone, and output-less runs collapse to a slim Output (none) header. New: clicking Run All again while it runs cancels the pass.
1.9.2 — README and listing overhaul: a hero demo GIF, a feature "At a glance" table, the four feature pillars (Highlight / Run / Embed / Share), and a rewritten store description. No functional changes.
1.9.1 — lint compliance: replaced banned obsidianmd/ui/sentence-case rule disables with an ignoreRegex allowlist, removed a CSS !important in favor of higher selector specificity.
1.9.0 — multi-language Jupyter export (#5): every executable block becomes a code cell; non-dominant blocks carry metadata.vscode.languageId so VS Code renders and round-trips them. Quality: cancellation polish, skip-badge alignment by code hash, fence-attribute isolation, Matplotlib style default corrected.
1.8.0 — interactive Plotly widgets and click-to-expand plots (#12); Jupyter .ipynb import/export and styled HTML/PDF export with outputs (#5); HTML live preview in a sandboxed iframe.
1.7.0 — full code-block chrome in Live Preview: header, Run/Copy, live output, line numbers, collapse, and ![[file.py]] embeds.
1.6.0 — typed vars/code_vars injection with :type hints and multiline strings (#16), live cross-language variable propagation, experimental data tables.
1.5.2 — soft-wrap long lines in reading view (#22), optional clear-session button (#23).
1.5.0 — explicit interpreter paths for bash/zsh/sh (#20), sh fence now runs POSIX sh.
1.4.0 — PHP support, PowerShell support, shell startup files, login-shell mode, Zsh-native variable snapshotter.
1.3.0 — code files in the file explorer, copy-output button, collapsible inline blocks, .env file support, codesuite:skip, code_vars: frontmatter, in-vault code editor, import-as-alias command.

Contributing

Found a bug or have a feature request? Open an issue on GitHub. Want to contribute code? See CONTRIBUTING.md.

Credits & license

Shiki — syntax highlighting engine (MIT)
Obsidian — the app this plugin is built for
CodeMirror 6 — editor framework used by Obsidian
