md2hd

Your vault, mapped. Right-click a note or folder, pick Open as md2hd map, and the structure you have been holding in your head becomes a tab you can read — frontmatter becomes typed nodes, wikilinks and rel: entries become labelled edges, and the map redraws itself as you edit.

Why

Obsidian's graph view shows you that links exist. md2hd shows you what they mean. Nodes carry types you invent — org, person, claim, scene, whatever the vault is about — and every link is a named relationship drawn in the right direction. The same canvas reads an org chart, a service map, an investigation, or a plot outline without knowing anything about any of them.

• The map is a read surface. Obsidian's editor stays the write path. Save a note and the open map redraws — no refresh, no re-import.
• Focus answers questions. Click a node and the map re-forms around it: what points at it on the left, what it points at on the right, with degree dials — 1st / 2nd / 3rd / X — that walk each direction further out.
• Every link speaks in the node's own voice. The same relationship reads employs from the organisation and works at from the person.
• Nothing leaves your vault. The map renders inside Obsidian from the notes on disk. No server, no network, no account, no telemetry.

Using it

Three ways in, all equivalent:

1. Right-click a note or folder → Open as md2hd map.
2. Command palette → md2hd: Map the current folder.
3. Command palette → md2hd: Map the whole vault.

The strip at the foot of the canvas holds the map's surfaces: the Overview, a tab per type, and — when you click a card — the node itself, detail beside connections. Search filters the whole map; drag to arrange.

The markdown

Every node is a frontmatter block; every [[wikilink]] or rel: entry is an edge. One optional type: map block configures the whole thing.

---
type: map
title: Partnerships
inverse:
  works_at: employs
---

---
id: riverside-council
type: org
title: Riverside City Council
weight: lead
rel:
  employs: [dana-whitfield]
---

The anchor relationship. Everything routes through [[dana-whitfield]].

Notes that were never written for md2hd usually read fine as-is: a --- line only opens a node when what follows looks like YAML, and malformed blocks degrade to prose instead of errors. Full syntax: md2hd.com/reference · guides

The agent skill

Writing a map by hand is easy; having a coding agent write one that compiles to the graph you meant is what the bundled skill is for. Run md2hd: Install skill and the plugin writes writing-md2hd-maps into your vault at .agents/skills/ and .claude/skills/ — the two places agents look, whichever one you run. Open the vault folder in your agent and "turn these notes into an md2hd map" produces markdown that opens as the map you asked for.

Install

Until the plugin lands in the community directory:

1. Download manifest.json and main.js from the latest release.
2. Put them in <vault>/.obsidian/plugins/md2hd/.
3. Enable md2hd in Settings → Community plugins.

Prefer the terminal? npx md2hd notes/ opens the same maps in a browser — that is the md2hd CLI, no Obsidian required.

Build from source

npm install
npm test     # builds main.js, then smoke-checks it

The repo is standalone — src/ carries the map renderer, synced out of the md2hd monorepo by maintainers (npm run sync, which needs the monorepo checkout around it).

Release

Releases are built from version tags by GitHub Actions. Update the same stable version in package.json, manifest.json, and versions.json, run npm test, commit the regenerated main.js, then push the exact version tag (for example, 0.2.4, without a v prefix). The workflow rebuilds the committed bundle, attests main.js, and publishes main.js with manifest.json.

After downloading an asset, its provenance can be checked with:

gh attestation verify main.js --repo evan-steinhilb/md2hd-obsidian

License

MIT
