Brickset LEGO

An Obsidian plugin that integrates with the Brickset API to fetch LEGO set information and formatted notes with set details and images.

Features

• Fetch LEGO Sets by Number - Simply enter a set number to retrieve complete set information
• Automatic Note Creation - Creates formatted markdown notes with all set details
• Image Integration - Downloads and embeds set images directly in your notes
• Rich Set Data - Includes pieces, minifigs, pricing, ratings, and more
• Metadata Support - Adds frontmatter tags for easy organization

Installation

From Obsidian Community Plugins

1. Open Obsidian Settings
2. Navigate to Community Plugins
3. Search for "LEGO"
4. Click Install
5. Enable the plugin

Manual Installation

1. Download the latest release from GitHub
2. Extract the files to your vault's .obsidian/plugins/brickset-lego/ folder
3. Reload Obsidian
4. Enable the plugin in Settings → Community Plugins

Setup

1. Configure the Plugin

1. Open Obsidian Settings
2. Navigate to Plugin Options → Brickset
3. (Optional) Configure the folder where LEGO set notes will be created
4. (Optional) Enter your Brickset username and password for personalized features
5. Click "Save Settings"

Usage

Fetch a LEGO Set

1. Open the Command Palette (Cmd/Ctrl + P)
2. Type "Fetch LEGO Set" and select the command
3. Enter the LEGO set number
4. Press Enter

The plugin will:

• Fetch the set data from Brickset
• Download set images
• Create a new note with all information
• Open the note for you to view

Example Set Numbers to Try

• 75192 - Millennium Falcon (UCS)
• 10497 - Galaxy Explorer
• 42143 - Ferrari Daytona SP3
• 10316 - Rivendell

Note Format

Each LEGO set note includes:

---
tags: lego, set
setNumber: 75192
theme: Star Wars
year: 2017
pieces: 7541
---

# 75192: Millennium Falcon

![Set Image](https://raw.githubusercontent.com/mirkostanic/obsidian-lego/HEAD/image-url)

## Details
- **Set Number:** 75192
- **Name:** Millennium Falcon
- **Theme:** Star Wars
- **Subtheme:** Ultimate Collector Series
- **Year Released:** 2017
- **Pieces:** 7541
- **Minifigs:** 8
- **RRP:** $799.99
- **Rating:** 4.8/5

## Description
The full set description fetched from Brickset appears here.

## Additional Images
![Additional Image 1](https://raw.githubusercontent.com/mirkostanic/obsidian-lego/HEAD/images/additional-1.jpg)
![Additional Image 2](https://raw.githubusercontent.com/mirkostanic/obsidian-lego/HEAD/images/additional-2.jpg)

## Links
- [Brickset Page](https://brickset.com/sets/75192-1)

## Notes
<!-- Add your personal notes here -->

Settings

Optional Settings

• LEGO Sets Folder - Folder where notes will be created (default: "LEGO Sets")
• Brickset Username - Your Brickset username (for personalized features)
• Brickset Password - Your Brickset password (for personalized features)

Troubleshooting

"Set Not Found" Error

• Verify the set number is correct
• Try searching on Brickset.com first
• Some very new or unreleased sets may not be available

Images Not Loading

• Check your internet connection
• Verify the vault has write permissions
• Try fetching the set again

Privacy & Security

Network and background behavior

This plugin does not send periodic telemetry or background beacons. A short internal timer runs while the plugin is enabled only to save a local JSON cache file inside the plugin folder (state-cache.json) so bidirectional sync can detect your edits. That timer performs vault disk I/O only and does not open network connections.

Data is sent to Brickset’s API over HTTPS only when you choose actions that require it, for example:

• Logging in from settings
• Running Fetch LEGO Set
• Running Sync LEGO collection from Brickset
• With Enable bidirectional sync turned on, updating qualifying fields in a LEGO note’s frontmatter (after the configured delay)

Enabling the plugin alone does not start collection-wide or bidirectional API traffic; those depend on the commands and toggles above.

Credentials and encryption

• No data is sent to any server except Brickset's official API.
• Optional username and password are stored in plaintext on the assumption that your Obsidian vault stays on a machine you control. (You could instead avoid storing the password and re-enter it when the session hash expires.)
• All API calls use HTTPS.

Development

Building from Source

# Clone the repository
git clone https://github.com/mirkostanic/obsidian-lego.git
cd obsidian-lego

# Install dependencies
npm install

# Build the plugin
npm run build

# Development mode (auto-rebuild on changes)
npm run dev

# Run tests
npm run test

# Run tests and show coverage
npm run test:coverage

# Run lint
npm run lint

# Run lint and attempt fix
npm run lint:fix

# Bump version
npm version X.Y.Z
npm run version

Project Structure

obsidian-lego/
├── src/
│   ├── main.ts              # Main plugin class
│   ├── settings.ts          # Settings tab + persistence
│   ├── stateCache.ts        # On-disk cache of previously synced frontmatter
│   ├── syncBackService.ts   # Obsidian → Brickset bidirectional sync
│   ├── syncService.ts       # Brickset → Obsidian collection sync
│   ├── bricksetApi.ts       # Brickset HTTP API service
│   ├── types.ts             # Type definitions
│   ├── noteCreator.ts       # Note generation
│   └── modal.ts             # User input modal
├── manifest.json            # Plugin manifest
├── package.json             # Dependencies
├── styles.css               # Styling
└── README.md                # This file

Contributing

Contributions are welcome. Please feel free to submit a Pull Request.

Development Guidelines

1. Follow TypeScript best practices
2. Add tests for new features
3. Update documentation
4. Follow the existing code style

Support

• Documentation
• Report Issues
• Discussions

Credits

• Built for Obsidian
• Data provided by Brickset
• LEGO® is a trademark of the LEGO Group

Tests

npm test              # Run all tests once
npm run test:watch    # Watch mode for development
npm run test:coverage # Generate coverage report

License

MIT License - see LICENSE file for details

Disclaimer

This plugin is not affiliated with, endorsed by, or sponsored by the LEGO Group or Brickset. LEGO® is a trademark of the LEGO Group of companies which does not sponsor, authorize or endorse this plugin. See DISCLAIMER.md for full text.
