A practical math-writing toolkit for Obsidian.
Enter LaTeX faster, reuse math or Markdown templates, and render TikZ with built-in WASM or optional local TeX.
English · 简体中文
Math Chords is an Obsidian writing toolkit built around mathematical Markdown. Its name comes from its chord-like leader shortcuts, but the plugin now covers the full path from entering a formula to reusing larger pieces of a note:
Math remains the primary workflow, but templates are deliberately not limited to formulas. They store raw Markdown in plugin settings and insert that source into the active note, so a template can be a Maxwell equation block, a proof scaffold, a lab-report section, or any other repeatable Markdown content. These templates are an insertion library, not vault files and not a replacement for Obsidian's file-based core Templates feature.
Default shortcuts are inspired by LyX math-mode bindings.
Current release: v0.5.16. See CHANGELOG.
Requires Obsidian 1.7.2+. Keyboard-heavy; desktop recommended.

Math Chords is an authoring layer for math-heavy Markdown notes: it speeds up structured LaTeX input, keeps recurring source reusable, normalizes imported math, and optionally renders TikZ without turning notes into a plugin-specific format. The built-in path is designed for everyday work; Obsidian's MathJax and an optional local TeX installation remain available where their broader compatibility matters.
| Feature | Description |
|---|---|
| Structured input | Press a configurable leader key, then a key sequence to insert common LaTeX structures and symbols. |
| Formula and template panel | Browse shortcuts or organize an unlimited tree of reusable math and Markdown templates, then click or drag content into a note. |
| Single-formula export | Save the selected or current formula as a vector SVG or transparent PNG. |
| Caret placeholder | $$ in a command template marks where the cursor (or selection) is placed, e.g. \frac{$$}{}. |
Auto $…$ wrap |
Optional: when inserting outside math, wrap the snippet in inline math delimiters. |
| Inline live preview | While the caret is inside $…$, a floating panel above the formula renders with Obsidian's native MathJax (on by default). |
| Brace navigation in math | Jump between {…} fields inside $…$ / $$…$$ with configurable keys (default Alt+→ / Alt+←; on by default). |
| Display-math environments | Wrap block content with \begin{…}…\end{…} via a fuzzy-search picker; inserts $$…$$ when needed. |
| Built-in math commands | Wrap selected text, insert inline/display math, or remove a matching wrapper; optional smart toggle enables conversion between inline and display math. |
| LaTeX delimiter conversion | Convert \(...\) / \[...\] to $...$ / $$...$$ in a selection, the current file, or optionally on paste, while excluding protected Markdown regions. |
| Optional TikZ rendering | Render fenced TikZ with the self-contained WASM backend, preview edits in a separate window, and export SVG, PNG, JPEG, or PDF; local TeX remains an advanced compatibility option. |
| YAML + UI config | Edit shortcuts.yaml or use the settings tab; changes rebuild the shortcut trie immediately. |
| Localized UI | All 72 locale bundles are included in main.js. Ten primary languages are maintained end to end; current English fallback text covers the remaining official Obsidian locales until reviewed translations are available. No language download is required. |
| Non-destructive merge | On load, missing default shortcuts are merged in; your custom key bindings are never overwritten. |
In Settings → Community plugins → Browse, search for Math Chords and install.
Obsidian's installer downloads main.js, manifest.json, and styles.css. Those three files contain every plugin feature and all 72 locale bundles; no second download is required.
Download main.js, manifest.json, and styles.css from Releases into .obsidian/plugins/math-chords/ inside your vault (create the folder if needed). Copy shortcuts.yaml from the repo only if you want the default shortcut catalog on disk.
git clone https://github.com/ichenh/obsidian-math-chords.git
cd obsidian-math-chords
npm install
npm run build
Copy main.js, manifest.json, styles.css, and optionally shortcuts.yaml into .obsidian/plugins/math-chords/.
Choose the workflow that matches what you are doing.
Alt+M).F inserts \frac{}{}, G A inserts \alpha, and D inserts a display-math block.$$ marker inside a configured snippet determines where the selection or caret lands. Enable shortcut hints if you want a which-key guide after pressing the leader.\(...\) or \[...\] and run Convert LaTeX Delimiters in Selection; use the current-file command for the whole note.For display environments, press Shift+E after the leader or run Wrap display math with environment. With only a caret inside math, the matching inline/display command removes that wrapper; with Smart math toggle enabled, the other command converts between inline and display math. A non-empty selection is always wrapped by the requested command.
Note: Shortcut tables list keys after the leader. The default leader is
Alt+M. Built-in commands do not register default hotkeys; assign them under Settings → Hotkeys if desired.
Select the sigma (Σ) ribbon icon or run Open formula panel. The optional right sidebar is enabled by default; disabling it removes the ribbon action, closes the panel, and makes the command unavailable until re-enabled.
The Shortcuts section uses the same catalog as leader input. Search matches keys, names, LaTeX commands, groups, folder names, template titles, and template content. Click a rendered shortcut to insert it at the editor's current selection, or drag the card to insert it at the exact Markdown editor position under the pointer. Math Chords handles the editor drop directly, so shortcut expansion, auto-wrap, and caret placement still apply. The Math environments group reads the editable environment list from settings; aligned, matrix, cases, and gathered show representative previews and can likewise be clicked or dragged into the editor in one undoable transaction.
The Templates section is a general reusable-content library optimized for math notes:
A template can be as focused as one Maxwell equation system or as broad as a reusable Markdown document section. Content is stored in Math Chords settings rather than as files in the vault.
Drag the left handles to reorder shortcut groups, the two main sections, template folders, or templates. Use the chevrons on the right to collapse individual sections and nodes; the summary action collapses or expands all shortcut groups, template folders, and template blocks together. Order and collapsed state persist across restarts.
Settings → Math Chords → Template management mirrors the panel tree. It supports search, root-level and nested creation, title/content editing, folder renaming, deletion, keyboard arrow reordering from a focused drag handle, and the same free drag-and-drop placement before, after, or inside folders. Shortcut management, template management, and their internal groups can all be collapsed so a long settings page remains navigable.
Panel insertion uses the same selection replacement, $$ caret marker, auto-wrap, display-math action, and cursor-placement rules as leader shortcuts. Reloading, merging, adding, editing, or deleting shortcuts refreshes open formula panels automatically. If no Markdown note is open, the plugin leaves the workspace unchanged and shows a notice.
| Keys | Inserts | Description |
|---|---|---|
F |
\frac{}{} |
Fraction |
S |
\sqrt{} |
Square root |
Shift+R |
\sqrt[]{} |
Nth root |
^ |
^{} |
Superscript |
Shift+_ |
_{} |
Subscript |
| Keys | Inserts | Description |
|---|---|---|
U |
\sum |
Sum |
I |
\int |
Integral |
Shift+I |
\int_{}^{} |
Integral with limits |
Y |
\oint |
Contour integral |
P |
\partial |
Partial derivative |
D |
\mathrm{d} |
Derivative |
Shift+P |
\prod_{}^{} |
Product |
L |
\lim_{} |
Limit |
8 |
\infty |
Infinity |
' |
' |
Prime |
+ |
\pm |
Plus-minus |
= | |
\neq |
Not equal |
| Keys | Inserts | Description |
|---|---|---|
" |
\ddot{} |
Double dot |
H |
\hat{} |
Hat |
\ |
\grave{} |
Grave |
/ |
\acute{} |
Acute |
& |
\tilde{} |
Tilde |
- |
\bar{} |
Bar |
. |
\dot{} |
Dot |
Shift+V |
\breve{} |
Breve |
Shift+U |
\check{} |
Check |
V |
\vec{} |
Vector arrow |
_ |
\underline{} |
Underline |
B |
\overline{} |
Overline |
A W |
\widehat{} |
Wide hat |
| Keys | Inserts | Description |
|---|---|---|
( |
\left(\right) |
Parentheses |
[ |
\left[\right] |
Square brackets |
{ |
\left\{\right\} |
Curly brackets |
< |
\left\langle\right\rangle |
Angle brackets |
> |
\left)\right( |
Reverse parentheses |
| |
\left|\right| |
Vertical bars |
B N |
\left|\right| |
Norm |
B F |
\left\lfloor\right\rfloor |
Floor |
B E |
\left\lceil\right\rceil |
Ceiling |
G + key)| Keys | Inserts | Keys | Inserts |
|---|---|---|---|
G A |
\alpha |
G N |
\nu |
G B |
\beta |
G O |
\omega |
G C |
\chi |
G P |
\pi |
G D |
\delta |
G Q |
\vartheta |
G E |
\epsilon |
G R |
\rho |
G F |
\phi |
G S |
\sigma |
G G |
\gamma |
G T |
\tau |
G H |
\eta |
G U |
\upsilon |
G I |
\iota |
G V |
\theta |
G J |
\varphi |
G X |
\xi |
G K |
\kappa |
G Y |
\psi |
G L |
\lambda |
G Z |
\zeta |
G M |
\mu |
G Shift+ + key)| Keys | Inserts | Keys | Inserts |
|---|---|---|---|
G Shift+D |
\Delta |
G Shift+S |
\Sigma |
G Shift+E |
\varepsilon |
G Shift+T |
\varsigma |
G Shift+F |
\Phi |
G Shift+U |
\Upsilon |
G Shift+G |
\Gamma |
G Shift+V |
\Theta |
G Shift+L |
\Lambda |
G Shift+O |
\Omega |
G Shift+P |
\Pi |
G Shift+X |
\Xi |
G Shift+Y |
\Psi |
Arrows (W prefix): W R \rightarrow, W L \leftarrow, W Shift+R \Rightarrow, W Shift+L \Leftarrow, W M \mapsto
Operators (O prefix): O T \times, O C \cdot, O D \div, O E \equiv, O L \leq, O G \geq, O A \approx, O I \in, O U \cup, O Shift+U \cap, O Shift+N \nabla
Fonts (T prefix): T B \mathbf{}, T C \mathcal{}, T R \mathrm{}, T Shift+R \mathbb{}, T T \text{}
Matrices (M prefix): M P pmatrix, M B bmatrix, M C cases. Their UI previews use compact 2-by-2 matrices or a two-row cases example; insertion still places the caret in an empty environment.
The full list lives in shortcuts.yaml (103 default shortcuts).
With the caret inside $$…$$, or anywhere else in the note (a block is created first if needed):
Press the configured shortcut after the leader (default Shift+E), or run Wrap display math with environment from the command palette.
Choose an environment from the fuzzy-search list.
The plugin wraps the entire block content (not only the selection) and keeps delimiters and environment markers on separate lines.
$$
\begin{aligned}
\alpha+\beta
\end{aligned}
$$
Creating a display block when needed and adding the environment are committed as one editor transaction, so one Undo reverts the command. Cancelling the picker does not modify the note.
Configure environments (name / \begin{…} / \end{…}) and the trigger keys under Display-math environment wrap in Settings → Math Chords, or assign a hotkey to the command in Settings → Hotkeys. On narrow settings panes, the environment table scrolls horizontally; compact order and name columns remain visible when space permits and are released on very narrow panes.
Default environments: aligned, matrix, cases, gathered.
shortcuts.yamlShortcuts are a YAML array. The leader key is global (settings), not per entry.
- keys: "F"
command: "\\frac{$$}{}"
name: "Fraction"
group: "Structures"
- keys: "G A"
command: "\\alpha"
name: "alpha"
group: "Greek"
| Field | Required | Description |
|---|---|---|
keys |
yes | Key sequence after the leader. Space-separated tokens; modifiers use + (Shift+S, G A). |
command |
yes | LaTeX snippet. Use $$ once for the caret/selection position. Write \frac not \\frac in the settings UI (auto-normalized). |
name |
no | Label in the settings table and which-key popup. |
group |
no | Grouping label in the settings table. |
Special command __DISPLAY_MATH__ inserts a $$…$$ block and can be assigned to a custom shortcut.
mod+base order: ctrl → alt → shift → meta.Shift is explicit (Shift+A).+ is a valid base key. For punctuation produced with Shift on the
current keyboard layout, an explicit Shift+symbol binding takes precedence;
otherwise the printable-symbol binding is used.Math Chords can replace standard LaTeX math delimiters while preserving the formula contents, whitespace, and line breaks:
\(...\) → $...$\[...\] → $$...$$Use Convert LaTeX Delimiters in Selection for selected text, or Convert LaTeX Delimiters in Current File for the active Markdown note. The whole-file command reports the number of display and inline formulas converted. Each command uses one editor transaction, so one Undo reverts the complete operation.
The converter leaves delimiters unchanged inside YAML frontmatter, fenced code blocks, inline code, HTML comments, HTML <pre> / <code> blocks, and existing $...$ / $$...$$ math. Existing Markdown math is recognized using delimiter rules that distinguish it from ordinary currency text. Multiple editor selections are processed in one transaction.
Enable Automatically convert pasted LaTeX math delimiters to apply the same context-aware conversion on paste. This setting is off by default. Paste conversion does not take over an event that another editor extension has already handled.
Enable Formula export and copying in the plugin settings first (off by default). Turning it off immediately removes the block and panel actions and hides the export commands and editor-menu entries.
| Control | What it does |
|---|---|
| Copy image (left) | Copies a transparent PNG to the clipboard, with no save dialog. |
| Download (middle) | Opens a format menu, then a save dialog for the chosen SVG or PNG. |
| Edit source (right, Live Preview) | Obsidian's native button for editing the formula source. |
Hover over either image action for an explanation, or focus it with the keyboard and activate it with Enter or Space. Actions always target that formula block.
Hover over a rendered display-math block and click the download icon at the top right. In Live Preview it sits immediately to the left of the native edit-source button; Reading view provides the same menu.
The copy-image button to the left of download copies a transparent PNG using MathJax. Paste it into PowerPoint or another image-capable application with Ctrl+V (Cmd+V on macOS), without saving a file or installing TeX.
MathJax is the default. The plugin only invokes local TeX when you explicitly choose a local TeX action; it does not install tools. TeX fonts and supported commands may differ from the MathJax preview.
Images use black formulas on a transparent background, regardless of the note's theme. PNG is suitable for quick copying and insertion; SVG keeps vector paths when resized. Copying currently provides PNG only. For an SVG, use Download.
If clipboard access fails, download a PNG and insert the file instead. Cancelling the save dialog does not export a file. If local TeX fails, the notice includes the available compiler diagnostic and source context; MathJax PNG remains a separate option. Neither copying nor downloading changes the note.
The formula panel, editor context menu, and commands also provide PNG (MathJax)
and SVG (local TeX) export. Command IDs remain export-current-formula-png and
export-current-formula-svg. For these commands, select one formula or place a
single caret inside Markdown math. A selection takes precedence. The block button
always exports the clicked formula, without moving the caret or changing the note.
Export excludes protected code, frontmatter, and HTML regions. For notes over 100,000 characters, use an explicit selection or the block button. PNG output is limited to 8,192 pixels per side and 16 megapixels in total. Rendering and saving errors are reported without writing an incomplete image.
TikZ rendering is optional and disabled by default to avoid taking over code blocks
already handled by another plugin. Enabling it immediately registers fenced blocks
using the configured identifier (default: tikz) in Reading view. The separately
opt-in editor preview never replaces or inserts content into CodeMirror layout:
clicking a TikZ block opens an independent draggable and resizable live-render
window, while clicking elsewhere closes it. The floating preview shows source until
its first diagram is ready and retains the previous successful frame during edits.
Rendered blocks in the note use a compact loading indicator; source is shown there
only when the initial render fails.
The floating diagram fits its window without scrollbars, while Reading-view diagrams
follow their SVG content height without creating an internal scrolling region. On
desktop, the export button opens the system save dialog directly; the chosen
.svg, .png, .jpg/.jpeg, or .pdf filename extension selects the output
format.
Reading view starts work only for diagrams near the viewport. Completed artifacts are kept in a bounded in-memory cache (up to 24 entries / 16 MiB) and a bounded persistent cache (up to 96 entries / 32 MiB), so revisiting unchanged diagrams usually avoids a new compile. Print-oriented Markdown exporters trigger and wait for every TikZ block, including blocks that were never scrolled into view. The settings page can copy a compact diagnostic report, clear these caches, or restart the render engines without adding a status-bar item.
\begin{tikzpicture}
\draw[->] (0,0) -- (2,0);
\node at (2.3,0) {$\rho$};
\end{tikzpicture}
TikZ is part of the same source-first workflow as formula input: the fenced source remains ordinary Markdown, and changing the backend does not rewrite the note. Math inside built-in-renderer nodes is typeset by Obsidian's MathJax, so formulas match ordinary Markdown math.
On desktop, hover over a rendered TikZ block to download SVG, PNG, JPEG, or PDF from its top-right download button. In Live Preview the button sits beside the native edit action; it is also available in Reading view and the floating preview. Downloading exports the clicked diagram without opening its source. It saves the current rendered result, using whichever backend produced that diagram, without switching engines or recompiling for export. These controls are hidden in print output.
pgfplots or circuitikz, document-specific macros and styles, full TeX text boxes, specialized OpenType/CJK font work, and cases where output must match a formal TeX build. Ordinary diagrams prefer the DVI-to-SVG path for crisp Markdown and print output. PDF-producing engines also convert to path-based SVG when installed dvisvgm or a sibling pdftocairo can convert the PDF, while retaining the original vector PDF for direct export. Math Chords detects TeX Live, MiKTeX, MacTeX, TinyTeX, Tectonic, and compatible executables through PATH or an override path.The built-in publication subset covers the common vocabulary used by STEM
diagrams: Cartesian and polar coordinates, bounded numeric macros and
\foreach loops, relative and named coordinates, lines and Bézier curves,
circles, ellipses, rectangles, grids, closed polygons, circular arcs, bounded
function and coordinate plots, standard line/color/opacity styles,
Latex/Stealth arrows, inline path labels, and rectangular or circular nodes.
Specialized libraries and constructs—including pgfplots, circuitikz,
matrices, graph drawing, calc coordinates, patterns, decorations, clipping,
shading, 3D coordinates, and scoped transformations—remain explicit
Automatic/local-TeX territory instead of being approximated silently.
This division keeps the common path fast and installation-free without removing the full TeX ecosystem as an explicit escape hatch. Math Chords does not download an engine or silently install TeX. Changing the backend immediately refreshes TikZ in every open Markdown view and the selected editor preview; source blocks do not need to be reopened individually.
Only render TikZ source you trust. Although the native backend disables shell escape and restricts TeX file access, TeX is a complex interpreter. The WASM backend stays inside Obsidian's renderer process and does not invoke local executables.
On desktop, choosing local TeX allows Math Chords to inspect configured and common TeX executable paths, create bounded work files under the system temporary directory, and launch the selected executable directly without a command shell. Export writes only to the path selected in the system save dialog. Clipboard access is limited to text supplied by user paste events and explicit actions to copy formula images or diagnostic reports. Formula-image copying requires the opt-in Formula export and copying setting. The plugin does not read or monitor clipboard contents in the background. Review tools may report Clipboard Access because these copy actions write to the system clipboard.
For screen readers, add a concise first-line description such as
% alt: Gravitational field around a point mass. The comment remains valid TikZ source
and becomes the rendered diagram's accessible name.
Open Settings → Math Chords. The settings UI follows your Obsidian display language when a translation is available. On Obsidian 1.13.0 and later, individual Math Chords settings are also indexed by Obsidian's settings search.
All 72 locale bundles are included in main.js, so community-plugin and manual
installations never need a separate language download. Ten primary translations are
maintained end to end; other Obsidian locales use current English fallback text where
a reviewed translation is not yet available.
| Setting | Default | Description |
|---|---|---|
| Enable plugin | on | Master switch for leader shortcuts. |
| Leader key | Alt+M |
Global prefix before shortcut keys; keys in YAML are what follows it. |
| Show shortcut hints | on | Which-key panel after the leader. |
| Auto-wrap outside math | on | Auto-insert $…$ around snippets when not in math. |
| Smart math toggle | on | Allow inline/display commands to convert an existing block to the other kind. Matching commands always remove their wrapper. |
| Inline math live preview | on | MathJax preview above $…$. |
| Enable TikZ rendering | off | Register TikZ fenced-code rendering immediately; restart after disabling only when the processor must be fully released for another plugin. |
| TikZ live preview while editing | off | Opening a TikZ block starts its first render immediately. Later edits render after a configurable pause, 250 ms by default, while the previous successful frame remains visible. |
| TikZ code-block identifier | tikz |
Text after the opening code fence; change it only when another renderer already uses tikz. |
| TikZ backend | Built-in | Use recommended self-contained WASM, explicit local TeX compatibility mode, or Automatic, which keeps supported diagrams on WASM and falls back only when faithful output cannot be promised. |
| Local TeX installation | auto-detect | Detect TeX from the system and common installation locations. An executable or distribution directory can override detection. |
| TikZ custom fonts | off | Automatic language-aware selection is used by default. Enable this advanced section to specify Latin, Simplified Chinese, Traditional Chinese, Japanese, or Korean families. |
| TikZ diagnostics | — | Copy backend availability and recent-render details, clear bounded caches, or restart render engines. |
| Enable formula panel | on | Show the searchable shortcut/template sidebar, including persistent favorites and a bounded 12-item recent-template row. Disabling it removes the ribbon action, closes the panel, and disables the command. |
| Brace navigation in math | on | Jump between {…} inside math; defaults Alt+→ / Alt+←. |
| Next / previous brace keys | Alt+→ / Alt+← |
Chords for brace navigation (when enabled). |
| Automatically convert pasted LaTeX math delimiters | off | Safely convert \(...\) / \[...\] in pasted text. |
| Enable environment wrap | on | Environment picker; creates and wraps $$…$$ in one transaction when needed. |
| Environment wrap keys | Shift+E |
Keys after the leader for the picker. |
| Math environments | 4 built-ins | Editable list for the picker. |
Built-in commands (assign or reassign under Settings → Hotkeys): Open formula panel, Insert inline math, Insert display math, Wrap display math with environment, Convert LaTeX Delimiters in Selection, Convert LaTeX Delimiters in Current File, Export SVG with local TeX (higher quality), Export current formula as transparent PNG.
No built-in command registers a default hotkey. Assign any desired bindings under Settings → Hotkeys.
Insert inline math: wrap a non-empty selection in $…$; with only a caret, insert inline math outside math, remove an existing inline wrapper, or convert display math when Smart math toggle is on.Insert display math: wrap a non-empty selection in $$…$$; with only a caret, insert display math outside math, remove an existing display wrapper, or convert inline math when Smart math toggle is on.When cross-kind conversion is disabled, invoking the other math command inside an existing block leaves the note unchanged and shows a notice instead of creating invalid nested delimiters. Converting display math to inline math removes one wrapper-adjacent line break and replaces remaining internal line breaks with spaces, because inline Markdown math cannot span lines reliably.
Shortcut management: shortcuts are grouped into compact, container-responsive sections. Each row keeps the readable name and raw LaTeX command while adding a derived MathJax preview and keycap-style sequence; narrow panes move keys and actions onto dedicated rows instead of clipping them. Visible previews render on demand so opening settings does not eagerly typeset the entire catalog. Search matches keys, names, commands, and groups without rebuilding the settings page. Add and edit operations use aligned native dialogs; deletions require confirmation. Reload re-reads YAML, and Merge defaults appends missing built-in shortcuts without overwriting yours. Formula previews are presentation-only and are never written to shortcuts.yaml.
Template management: templates use the same recursive tree and free reordering as the formula panel. Drag a handle to reorder siblings, move an item into another folder, or return it to the root; focus a handle and use the arrow keys for same-level reordering. Root and folder toolbars distinguish new folder from new template. Empty folders are allowed, and search matches template titles and Markdown bodies. Titles, source content, tree order, and collapsed state are saved in plugin settings.
When the plugin loads (or you click Reload or Merge defaults):
keys → same binding).shortcuts.yaml.To reset completely, delete shortcuts.yaml and reload the plugin (a fresh default file will be seeded).
Regenerate the repo's default YAML from TypeScript:
npm run seed
math-chords/ # Plugin id; install folder .obsidian/plugins/math-chords/
├── src/ # TypeScript source
│ ├── main.ts # Plugin entry
│ ├── leader.ts # Leader shortcut state machine
│ ├── braceNav.ts # Brace-pair navigation inside math
│ ├── delimiterConverter.ts # Pure, protected LaTeX delimiter conversion
│ ├── delimiterEditor.ts # Obsidian editor transactions for conversion
│ ├── formulaPanel.ts # Searchable Obsidian formula sidebar
│ ├── formulaPanelModel.ts # Pure panel grouping and filtering model
│ ├── markdownProtection.ts # Shared Markdown protected-region parser
│ ├── mathToggle.ts # Pure inline/display toggle and conversion planning
│ ├── mathEnvPlan.ts # Pure single-transaction environment planning
│ ├── defaults.ts # Default shortcut catalog
│ ├── config.ts # YAML load/save/merge
│ ├── shortcutPreviewRenderer.ts # Shared lazy MathJax preview rendering
│ ├── l10n/ # compressed offline locale bundles
│ ├── tikz/ # scheduling, backends, preview, safety, export
│ └── … # math, templates, settings UI, etc.
├── crates/
│ └── chord-tikz-core/ # original dependency-free Rust/WASM renderer
├── tests/
│ ├── unit/ # Vitest unit and regression tests
│ └── performance/ # Opt-in parser performance baselines
├── vitest.config.ts
├── shortcuts.yaml # Shipped default shortcuts (103 entries)
├── styles.css # Preview & settings styles
├── manifest.json # Obsidian plugin manifest
├── scripts/ # Generation, shared utilities, and validation
├── .github/ # CI, release, Dependabot, and contribution templates
├── AGENTS.md # Canonical Codex, engineering, and workflow rules
├── ARCHITECTURE.md # Runtime, renderer, cache, and trust boundaries
├── CONTRIBUTING.md # Contributor workflow and submission requirements
├── SECURITY.md # Private vulnerability reporting policy
├── CODE_OF_CONDUCT.md # Community participation standards
├── eslint.config.mts # Obsidian-aware lint configuration
├── .editorconfig # Editor encoding and whitespace defaults
├── .gitattributes # Repository line-ending and binary-file rules
└── esbuild.config.mjs # Build config
Development requires Node.js 20.19+ or 22.12+, as declared in package.json.
npm install
npm run dev # watch build
npm run lint # ESLint + Obsidian plugin rules
npm run build # typecheck + production bundle
npm test # Vitest unit tests
npm run bench # opt-in parser and delimiter-conversion benchmarks
npm run seed # rewrite shortcuts.yaml from src/defaults.ts
npm run check:shortcuts # verify shortcuts.yaml matches src/defaults.ts
npm run seed:locales # bundled TS locales from scripts/locale-catalog.json
npm run check:locales # verify locale schema and generated artifacts
npm run check:release # verify metadata, changelog, and README version references
npm run check # complete build, test, generated-artifact, and metadata verification
Canonical Codex guidance and module, safety, generation, and release rules:
AGENTS.md. The repository does not define .codex/config.toml
because it currently needs no project-specific Codex runtime overrides.
Pull requests welcome. Follow CONTRIBUTING.md, run npm run check
before submitting, and perform relevant manual Obsidian testing for editor-integrated
behavior.
Community participation follows the Code of Conduct. Report security vulnerabilities privately using the Security Policy.
Potential future work and its design constraints are tracked in ROADMAP.md.
package.json, package-lock.json, and manifest.json; add its minimum-app mapping to versions.json.Unreleased changelog section with a dated release section and create a new empty Unreleased section above it. Update the current-release line in both READMEs; the release badges track the latest GitHub release automatically.npm run check, review the release assets, and complete the relevant manual Obsidian acceptance checks.v prefix), e.g. git tag 0.3.0 && git push origin 0.3.0.main.js, manifest.json, and styles.css, and creates artifact attestations for every asset. Existing releases are not deleted or recreated.This repository has used AI-assisted development tools, including Cursor and large language models, and is now maintained primarily with OpenAI Codex. These tools support tasks such as drafting, refactoring, test design, documentation, and consistency checks. Project decisions, accepted changes, and releases remain the maintainer's responsibility.
